    Spherical Iron Powder

    Spherical Iron Powder
  • Spherical Iron Powder
  • Spherical Iron Powder
  • Spherical Iron Powder
  • Spherical Iron Powder
  • Iron Powder

    Iron powder is a kind of important metal powder for powder metallurgy, and it requires a large quantity of Fe powder accounts for 85% of the total metal powder. Iron powder is mainly used in manufacturing machine parts.
    Iron-based alloy powder can be used on the working layer of abrasion-resistant anticorrosive parts, such as hydraulic turbine blade, nozzle, wearing ring, hydraulic rod. The stainless steel powder has a good sphericity configuration with low oxygen content, high hardness, and good toughness.
    The iron powder should be stored in a cool, dry, well-ventilated warehouse and kept away from fire and other heat sources. Relative humidity should remain below 75%. The packing must be sealed, do not be affected with damp. It should be kept apart from alkali, alcohol, and it should avoid mixed reservoir by all means. The storage area should be equipped with the right material in the case of leakage.

    Where to buy iron powder? AEM can supply different kinds of high purity Iron Metal Powders. If you do not find the sizes or compositions you need, please contact us via email. We have customized sizes and compositions according to customer's requests.

    Iron Metal powder

    Electrolytic Iron Powder is the purest form of iron powder produced by electrodeposition under controlled conditions. Our Electrolytic Iron Powder is 99.0% pure. Mesh size is offered as per customers' requirements.

    Grade Product Name Chemical Composition Particle Size Apparent Density (g/cm3)
    Fe-1 Iron powder Fe:  ≥ 99.0%
    Other: ≤ 1.0%
     -200 mesh
    Customed sizes avaliable
    -
    Fe-2 Iron powder  Fe:  ≥ 99.0%
    Other: ≤ 1.0%
     2- 4 um, D50: 18-27 um
    Customized sizes avaliable
    0.5-15


    Spherical Iron Based Alloy Powder

    Iron powder is a kind of important metal powder for powder metallurgy, and it requires a large quantity of Fe powder accounts for 85% of the total metal powder. Iron powder is mainly used in manufacturing machine parts.
    Iron-based alloy powder can be used on the working layer of abrasion-resistant anticorrosive parts, such as hydraulic turbine blade, nozzle, wearing ring, hydraulic rod. The stainless steel powder has a good sphericity configuration with low oxygen content, high hardness, and good toughness.
    AEM can supply different kinds of Iron-Based Alloy Powder in high purity. If you can't find the sizes or compositions you need, please contact us by email. We have customized sizes and compositions according to customer's requests.

    Grade:
    Stainless steel powder: 304, 316L, 410L, 15-5PH, 17-4PH, 2Cr13
    High-strength steel powder: A100, 300M, 30CrMnSiA, 40CrMnSiMoVA
    Tool steel powder: 18Ni300, H13, M2, M35, M42, T15, 2030, S390
    Iron-nickel alloy powder: Invar 36

    Standard: GB/T 3077, GB/T 1299, GB/T 1480, GB/T 5329, GB/T 8180
    Particle size: 0-20μm, 15-45μm, 15-53μm, 53-105μm, 53-150μm, 105-250μm
    Shape: Spherical, Ψ0≥0.85
    Appearance: Gray
    3D Printing Application: SLM, LMD
    Other Application: PM, MIN, HIP, SP, welding repair
    Package: Vacuum packaging (Aluminum foil bag) or argon-filled protective packaging (Aluminum bottle)

    Chemical Composition of Iron Based Alloy Powder

    Grade Chemical Composition (wt.%)
    C Cr Ni Mn Mo Si Nb Cu Co Ti Al V P O N S Fe
    304 ≤0.07 17-19 8-10 ≤2   ≤1             ≤0.035     ≤0.03 Bal.
    304L ≤0.03 18-20 8-10 ≤2   ≤1             ≤0.035     ≤0.03 Bal.
    316 ≤0.08 16-18.50 10-14 ≤2 2-3 ≤1             ≤0.035     ≤0.03 Bal.
    316L ≤0.03 16-18 12-15 ≤2 2-3 ≤1             ≤0.035     ≤0.03 Bal.
    410 ≤0.15 11.5-13.5   ≤1   ≤1             ≤0.035     ≤0.03 Bal.
    420 1.06-0.25 12-14   ≤1   ≤1             ≤0.035     ≤0.03 Bal.
    430 ≤0.12 16-18 ≤0.6 ≤1   ≤0.75             ≤0.04     ≤0.04 Bal.
    630 ≤0.07 15.5-17.5 6.5-7.5 ≤1   ≤1 0.15-0.45 3-5         ≤0.035     ≤0.03 Bal.
    17-4PH ≤0.07 15.5-17.5 3-5 ≤1   ≤1 0.15-0.45 3-5         ≤0.035     ≤0.03 Bal.
    15-5PH ≤0.07 14-15.5   ≤1   ≤1 0.15-0.45 2.5-4.5         ≤0.04 ≤0.05 3.5-5.5 ≤0.03 Bal.
    2Cr13 0.16-0.25 12-14   ≤1   ≤1             ≤0.035 ≤0.05 ≤0.6 ≤0.03 Bal.
    SCM415 0.13-0.18 0.9-1.2   0.6-0.85 0.15-0.3 0.15-0.35             ≤0.04     ≤0.03 Bal.
    S301 ≤0.15 16-18 6-8 ≤2   ≤1             ≤0.045 ≤0.05 ≤0.1 ≤0.03 Bal.
    S310 ≤0.08 24-26 19-22 ≤2   ≤1.5             ≤0.045 ≤0.05   ≤0.03 Bal.
    S220 ≤0.03 22-23 4.5-6.5 ≤2 3-3.5 ≤1             ≤0.03 ≤0.05 0.14-0.2 ≤0.02 Bal.
    18Ni300 ≤0.03 ≤0.3 17-19 ≤0.1 4.5-5.2 ≤0.1     8.5-9.5 0.6-0.8 0.05-0.15   ≤0.01 ≤0.05   ≤0.01 Bal.
    H13 0.32-0.45 4.75-5.5   0.2-0.5 1.1-1.75 0.8-1.2           0.8-1.2 ≤0.03 ≤0.05   ≤0.03 Bal.
    1.2709 ≤0.03 ≤0.25 17-19 ≤0.15 4.5-5.2 ≤0.41     8.5-10 0.8-1.2     ≤0.01 ≤0.05   ≤0.01 Bal.


    Self-fusing Iron Base Alloy Powder

    Self-fusing Iron base alloys are Iron-Carbon alloys with additions of Chromium, Boron, and Silicon. These are typically used on mechanical parts for resisting wear and weak acid corrosion. Even though their properties are not as good as Nickel, Cobalt base alloys, they are readily available and inexpensive, making them popular.

    Products Series

    Grade Hardness (HRC) Chemical Composition Particle (mesh) Application
    C Cr Si Fe Mo Ni Mn B Other
    Fe1 35-40 0.15 22 4.5 Bal. 2 13   1.6   100/270 Valve
    Fe2 38-44 0.15 22 4.5 Bal. 2 10   1.8   100/270 Valve seat
    Fe5 62-67 4.5 40 1 Bal.     0.97 1.8   100/270 Drilling pipe joint
    Fe90 50-55 0.15 13.5 1.3 Bal.       1.6   100/270 Drilling pipe joint
    Fe6 58-60 0.8 7.5 2 Bal.   32   4   100/270 Fan blades
    Fe45 40-46 0.6 7.5 2 Bal.   22   3   100/270 Paper-making machines
    Fe304 HB190 0.03 18 0.1 Bal.   10 0.3     100/270 Paper-making machines
    Fe316L HB190 0.03 17 0.2 Bal. 2.5 12 0.5     100/270、300/500 Paper-making machines
    Fe410L HB220 0.03 12.5 0.5 Bal.     0.1     100/270、 300/500 Pistons
    JG-1 19 0.03 17 0.8 Bal.     0.3 1.3     Pistons
    JG-2 26 0.04 17 0.3 Bal.     0.2 2.6     Pistons
    JG-3 46 0.12 16.5 0.8 Bal.       0.9     Pistons
    JG-4 63 1 4 0.3 Bal. 5   0.3       Pistons
    Fe253 35 1.75 28 1.3 Bal. 4.5 16 0.8     100/270 Engine valve
    Fe253H 40 2.1 28 1.2 Bal. 5.5 11.5 1     100/270 Engine valve
    Fe101 62 3.3 2 1 Bal.   5 1 1.4   20/300 Extrusion barrels
    Fe102 62 2.7 2.8 1 Bal.   5.5 1 1.9   20/300 Extrusion barrels
    Fe103 62 1.5 4.5 1 Bal.   7 1 2.9 W:4.5 20/300 Extrusion barrels
    Fe104 60 1.7 4.5 1.5 Bal.   11 0.8 3   20/300 Extrusion barrels
    Fe105 62 1.5 4.5 1.3 Bal. 1.5 12 1 2.8   20/300 Extrusion barrels
    Fe106 62 1.08 5.42 2.01 Bal.   27 0.89 3.08   20/300 Extrusion barrels
    Fe107 62 1.36 6.25 1.56 Bal.   16.2 1.02 2.98   20/300 Extrusion barrels
